IT WORKED *pics* Gas Turbine Engine
 Post Reply Post Reply Page  123>
Author
Message
  Topic Search Topic Search  Topic Options Topic Options
WGP guy2 View Drop Down
Platinum Member
Platinum Member
Avatar
I play the Bag Pipes

Joined: 23 September 2005
Location: 17h 45m 40.04s
Status: Offline
Points: 2585 		Post Options Post Options   Thanks (0) Thanks(0)   Quote WGP guy2 Quote  Post ReplyReply Direct Link To This Post Topic: IT WORKED *pics* Gas Turbine Engine
    Posted: 07 April 2007 at 7:52pm
*UPDATE*

So I fired it up today.  I turned on the propane, turned on the blower, turned on the ignitor...and nothing happened.  I messed with it for about an hour and finally got a few flames.  Then I messed with it some more, got it to catch on fire a few times, and finally, a sustained flame.  Very cool blue flame was inside of it, I had it on the only mixture setting I could get to work. It didn't make too much thrust, but it was enough that my body got hot standing 5 feet behind it. The duct tape you see on the back was to restrict airflow, it was temporary and will be replaced with metal when I get back from Daytona.   Pics of it working:







*ORIGINAL*



So, with the temporary pause in schoolwork (spring break) I decided to start a new project, a gas turbine engine (turbojet engine).  I've had much interest in them and have a very good understanding of how they work, enough that with a little research I made a plan to build one.

So, I went to Home Depot, and spent about $50 on parts (and another $30 in tools) to build one.

I'm nearly finished with the burner, which I will be testing before I add a compressor and turbine to it.  The burner is the part that takes the real engineering on my part, so it will be the thing that takes the longest.

I am almost finished with the first try at a burner, I have everything installed (outer casing, inner casing (burner can), propane line, and nozzle) except the ignition system, which I have sitting right beside me but I don't feel like putting in right now.

Hopefully I will fire this thing up for a trial run tomorrow, however I'm leaving tomorrow night to go to Daytona Beach, so it might be the end of this week.  I will get more pics and probably a vid when I get it running good.  Some pics:










Edited by WGP guy2 - 08 April 2007 at 5:38pm
